Unique Feature
|
- PCIe Gen5 (Graphics, M.2)
- Eight Channel DDR5
- USB4 Type-C Ports (40 Gb/s)
- Ultra Low-Loss PCB
- 18+3+3 Power Phase, 110A SPS for VCore
- 20K Long-lasting Black Caps
|
|
CPU
|
- Supports AMD Ryzen™ Threadripper™ PRO 9000/7000 WX-Series
- AMD Socket sTR5
- ASRock Hyper BCLK Engine
|
|
Chipset
|
AMD WRX90
|
|
Memory
|
- Eight Channel DDR5
- 8 × DDR5 DIMM Slots (ECC, Buffered RDIMM/RDIMM-3DS)
- Up to 7600+(OC), Max. 2TB
*S3 sleep only with 1/2/4 DIMMs
|
|
BIOS
|
256Mb AMI UEFI Legal BIOS with GUI
|
|
Graphics
|
- Aspeed AST2600 BMC Controller
- 1 × DisplayPort 1.1a (Max 1920x1200 @60Hz, no audio)
|
|
Audio
|
- 7.1 CH HD Audio (Realtek ALC1220)
- Nahimic Audio
- Individual PCB for R/L
- Impedance Sensing
|
|
LAN
|
- 2 × Intel® X710-AT2 10G LAN
- 1 × Realtek RTL8211F for IPMI
- PXE support
|
|
Slots
|
- 7 × PCIe 5.0 x16 (PCIE1-7), PCIE6 runs x8
- 15μ Gold VGA contacts
*Supports NVMe boot
|
|
Storage (CPU)
|
- 1 × Blazing M.2 (Gen5x4)
- 2 × MCIO (PCIe Gen5x4 or 4x SATA)
- 1 × SlimSAS (Gen4x4 or 4x SATA)
|
|
Storage (Chipset)
|
- 1 × Hyper M.2 (Gen4x4)
- 1 × SlimSAS (Gen4x4)
- 4 × SATA3 (6 Gb/s)
|
|
RAID
|
- RAID 0, 1, 10 (SATA)
- RAID 0, 1, 10 (NVMe M.2)*
*RAID 10 requires add-on card
|
|
USB (CPU)
|
- 2 × USB4 Type-C (Rear)
- 4 × USB 3.2 Gen2 Type-A (Rear)
|
|
USB (Chipset)
|
- 1 × USB 3.2 Gen2x2 Type-C (Front)
- 4 × USB 3.2 Gen1 Type-A (2 Rear, 2 Front)
- 4 × USB 2.0 (Front)
|
|
Internal Connectors
|
- Thermistor, VGA, COM, IPMB, SMBus, LED, PSU SMBus, BMC SMBus, Aux Panel
- 2 × ARGB Headers (5V/3A)
- Fan: 1 × CPU, 1 × CPU/W_Pump (2A), 3 × CHA/W_Pump (2A)
- Power: 1 × 24-pin, 1 × 3-pin ATX, 2 × 8-pin ATX12V (motherboard), 2 × 6-pin PCIe 12V (motherboard), 2 × 6-pin Graphics 12V
- Front Audio, USB2.0 (x2), USB3.2 Gen1, USB3.2 Gen2x2 (20Gb/s), SGPIO x2
- CPU HP-SMBus, NMI Button Header, Dr. Debug, Power/Reset/CMOS Button
|
|
Rear I/O
|
- 1 × DisplayPort 1.1a
- 1 × Optical SPDIF Out
- 2 × USB4 Type-C (40 Gb/s)
- 4 × USB 3.2 Gen2 Type-A
- 2 × USB 3.2 Gen1 Type-A
- 2 × RJ-45 10G LAN
- 1 × RJ45 IPMI
- Audio: Line Out, Mic In (Gold Jacks)
|
|
Software
|
- ASRock Polychrome SYNC
- ASRock Full HD UEFI
- ASRock Auto Driver Installer
- ASRock Instant Flash
|
|
Accessories
|
- User Manual
- I/O Shield
- 4 × SATA Cables
- 2 × Thermistor Cables
- 1 × Multi PSU Adapter
- 2 × M.2 Screws
- 2 × M.2 Standoffs
|
|
Form Factor
|
EEB (30.5 × 33.0 cm / 12.0 × 13.0 in), 14-Layer PCB, 2oz Copper
|
|
OS Support
|
Microsoft Windows® 11 64-bit
|
|
Certifications
|
FCC, CE, ErP/EuP Ready, CEC Tier II
|
