Feature | Specification |
Standard Compliance | ATX 12V 2.31 |
Dimensions (L x W x H) | 140mm x 150mm x 85mm |
Regulatory Certifications | CE/CB |
Efficiency | Typical load efficiency > 72% |
Hazardous Materials | ROHS compliant |
Fan Technology | Hydro Bearing |
Fan Size | 120mm |
Adjustable 12V Rail | Yes |
Input Voltage | 200-240VAC |
Input Current | 6.3A |
Input Frequency Range | 50-60Hz |
Power Good Signal | 100-500ms |
Hold Up Time | >10ms |
Protection Functions | OPP, OVP, UVP, SCP, OTP, SPD |
Operating Temperature | 0~40°C |
Modular | No |
Cable Type | Normal |
ATX 24Pin Connector | 1 |
CPU (4+4)Pin Connector | 1 |
PCIe 6Pin Connector | 0 |
IDE Connector | 2 |
SATA Connector | 4 |
FDD Adapter | 0 |
MTBF | 50,000 Hours |
Net Weight | 1.13kg |
