ASUS ROG STRIX Z890-I GAMING WIFI (LGA1851, Z890, DDR5, USB3.2 GEN2X2 TYPE-C, SATA3)

Kategori

Spesifikasi

Model

ROG STRIX Z890-I GAMING WIFI

CPU

Mendukung Intel® Core™ Ultra Processors (Seri 2)
Intel® Turbo Boost 2.0 & Turbo Boost Max 3.0*

Chipset

Intel® Z890

Memori

2× DIMM DDR5, Maks 128GB
DDR5 hingga 9200+ MT/s (OC), Non-ECC, Un-buffered
Dual-Channel, XMP, DIMM Flex, DIMM Fit, AEMP III

Grafis

1× HDMI 2.1 (4K@60Hz)
2× Thunderbolt™ 4 (DP & TB video output, USB-C)

Slot Ekspansi

CPU: 1× PCIe 5.0 x16 (x16 mode)

Penyimpanan

2× M.2 (Key M) + 2× SATA 6Gb/s*
M.2_1: PCIe 5.0 x4
M.2_2: PCIe 5.0 x4 (berbagi bandwidth dengan PCIEX16)
Intel RST: PCIe RAID 0/1, SATA RAID 0/1
*Instal ROG FPS Card untuk mengaktifkan 2× SATA 6Gb/s

Ethernet

1× Intel® 2.5Gb Ethernet + ASUS LANGuard

Wireless & Bluetooth

Wi-Fi 7 2×2 (802.11be)
2.4/5/6 GHz, Wi-Fi 7 320MHz, hingga 5.8Gbps
Bluetooth 5.4

USB Belakang

Total 9 port:
2× Thunderbolt™ 4 (USB-C)
1× USB-C 20Gbps
3× USB 10Gbps Type-A
1× USB 5Gbps Type-A
2× USB 2.0 Type-A

USB Depan

Total 3 port:
1× USB-C 20Gbps
1× USB 5Gbps header (2 port tambahan)

ROG STRIX HIVE II

2 port: 1× USB-C 10Gbps + 1× USB-A 10Gbps
Audio: headphone jack + mic in
Power, FlexKey, Volume knob + mute

ROG FPS Card

3 port tambahan: 2× USB 2.0 headers, 2× SATA 6Gb/s

Audio

ROG Hyper-Grounding, ESS SABRE9260Q DAC, silver-plated jacks, dedicated PCB layers

Back Panel I/O

2× Thunderbolt™ 4, 1× USB-C 20Gbps, 3× USB 10Gbps, 1× USB 5Gbps, 2× USB 2.0
HDMI, Wi-Fi module, Intel 2.5Gb Ethernet, BIOS FlashBack™

Internal I/O

1× CPU Fan, 1× AIO Pump, 1× Chassis Fan, 1× Extra Flow Fan
1× 24-pin ATX, 1× 8-pin EPS
2× M.2 slots, USB-C 20Gbps, USB 5Gbps header
2× ARGB Gen2 headers, 1× Power Button header, 1× Thermal Sensor, 2× USB-C connectors (FPS Card), CPU OV jumper, Clear CMOS, Front Panel header, PCIe mode switch, USB 2.0 headers

Fitur Khusus

Extreme Engine Digi+ (5K Black capacitors)
ASUS Q-Design: M.2 Q-Release Duo, PCIe Q-Release Slim, Q-Antenna, Q-Dashboard, Q-DIMM, Q-Slot
ASUS Thermal: M.2 heatsink & backplate, VRM heatsink, Fan bracket
EZ DIY: BIOS FlashBack™, CPU socket protector, ProCool II, pre-mounted I/O shield, SafeDIMM, backplate
Aura Sync: Addressable Gen2 headers
Q-LED (CPU/DRAM/VGA/Boot Device)

Software

ROG CPU-Z, Dolby Atmos
Armoury Crate, Aura Creator, Aura Sync, Fan Xpert 4, GameFirst, Power Saving, HWiNFO
AIDA64 Extreme (trial), ASUS AI Advisor, Driver Hub, GlideX, Adobe CC (trial), Norton 360 (trial), WinRAR (trial)
UEFI BIOS: AI Overclocking Guide, CrashFree BIOS 3, EZ Flash, EZ Mode, MyHotkey, NPU Boost

BIOS

256 Mb UEFI AMI BIOS

Manageability

WOL oleh PME, PXE

Aksesoris

ROG USB2.0 splitter, 2× SATA 6Gb/s, Panel Cable, ROG FPS Card, ROG STRIX HIVE II, USB-C power cable, Wi-Fi Q-Antenna, Cable ties, ROG key chain, ROG Strix stickers

Dokumentasi

1× Quick Start Guide

OS Support

Windows 11 (22H2 & lebih baru)

Form Factor

Mini-ITX – 17×17 cm
