CPU
|
- AMD Socket AM5
- Mendukung AMD Ryzen™ 9000 / 8000 / 7000 Series Processors
- (Lihat daftar dukungan CPU terbaru di situs GIGABYTE)
|
|
Chipset
|
AMD X870
|
|
Memori
|
- Mendukung DDR5: 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C) / 7400(O.C) / 7200(O.C) / 7000(O.C) / 6800(O.C) / 6600(O.C) / 6400(O.C) / 6200(O.C) / 6000(O.C) / 5800(O.C) / 5600(O.C) / 5200 / 4800 / 4400 MT/s
- 4 x DDR5 DIMM (maks. 256 GB, 64 GB per DIMM)
- Dual Channel Architecture
- Mendukung non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16
- Mendukung AMD EXPO™ & Intel XMP Profiles
|
|
Grafis Terintegrasi
|
Dengan ASMedia USB4® Controller:
- 2 x USB4® Type-C® (DisplayPort, 3840×2160@240Hz, DP 1.4, HDR)
Grafis AMD Radeon™:
- 1 x HDMI 2.1 (4096×2160@60Hz, HDCP 2.3, HDR)
- Mendukung hingga 3 display simultan (tergantung CPU)
|
|
Audio
|
- Realtek® ALC1220 CODEC (HD Audio)
- 2/4/5.1/7.1 channel
- Mendukung DSD Audio (line-out belakang)
- Mendukung S/PDIF Out
|
|
LAN
|
- Realtek® 5GbE LAN (5G/2.5G/1G/100M)
|
|
Wi-Fi & Bluetooth
|
- Qualcomm® Wi-Fi 7 QCNCM865 (802.11a/b/g/n/ac/ax/be, 2.4/5/6GHz)
- BLUETOOTH 5.4
- Mendukung 320MHz 11be standard
Wi-Fi 7 hanya berfungsi penuh di Windows 11 SV3
|
|
Slot Ekspansi
|
CPU:
- 1 x PCIe x16 (Ryzen 9000/7000: PCIe 5.0 x16, Ryzen 8000 Phoenix1: PCIe 4.0 x8, Phoenix2: PCIe 4.0 x4)
Chipset:
- 1 x PCIe x16 (PCIe 4.0 x4, berbagi bandwidth dengan M2D_SB)
|
|
Penyimpanan (Storage)
|
CPU:
- 1 x M.2 (M2A_CPU) PCIe 5.0/4.0 x4/x2 (type 25110/22110/2280/2580)
- 1 x M.2 (M2B_CPU) PCIe 5.0/4.0 x4/x2 (type 22110/2280) (nonaktif dengan Ryzen 8000 Phoenix2)
Chipset:
- 2 x M.2 (M2C_SB & M2D_SB) PCIe 4.0 x4/x2 (type 22110/2280)
- 2 x SATA 6Gb/s
RAID: NVMe RAID 0/1/5/10 (RAID 5 hanya di Ryzen 9000); SATA RAID 0/1
|
|
USB
|
CPU + ASMedia USB4 Controller:
- 2 x USB4® Type-C® (DisplayPort, Back Panel, berbagi bandwidth dengan M2B_CPU)
CPU:
- 1 x USB Type-C® (USB 3.2 Gen 2, Back Panel)
CPU + Hub USB:
- 4 x USB 3.2 Gen 1 (Back Panel)
- 4 x USB 2.0 (Back Panel)
Chipset:
- 1 x USB Type-C® (USB 3.2 Gen 2x2, internal header)
- 2 x USB 3.2 Gen 2 Type-A (merah, Back Panel)
- 2 x USB 3.2 Gen 1 (internal header)
- 4 x USB 2.0 (internal header)
|
|
Internal I/O
|
- 1 x 24-pin ATX
- 1 x 8-pin + 1 x 4-pin ATX 12V
- 1 x CPU Fan + 1 x CPU/WPUMP
- 4 x System Fan + 2 x System/WPUMP
- 3 x ARGB Gen2 + 1 x RGB Header
- 4 x M.2 Socket 3
- 2 x SATA 6Gb/s
- 1 x Front Panel + 1 x Front Audio
- 1 x USB-C (USB 3.2 Gen 2x2)
- 1 x USB 3.2 Gen 1
- 2 x USB 2.0
- 1 x Noise Detection
- 1 x TPM Header
- 1 x Q-Flash Plus Button
- 1 x Power Button
- 1 x Reset Button + Jumper
- 2 x Temp Sensor Header
- 1 x Clear CMOS Jumper
|
|
Back Panel I/O
|
- 1 x HDMI
- 2 x USB4® Type-C® (DisplayPort)
- 1 x USB-C (USB 3.2 Gen 2)
- 2 x USB 3.2 Gen 2 Type-A (merah)
- 4 x USB 3.2 Gen 1
- 4 x USB 2.0
- 2 x Antenna (2T2R)
- 1 x RJ-45 (5GbE)
- 1 x Optical S/PDIF Out
- 2 x Audio Jack
|
|
Kontroler I/O
|
iTE® I/O Controller Chip
|
|
Monitoring Hardware
|
- Voltage, Temperature, Fan Speed, Water Flow
- Fan Fail Warning & Fan Speed Control
|
|
BIOS
|
- 1 x 512 Mbit Flash ROM
- AMI UEFI BIOS
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
|
|
Fitur Unggulan
|
- GIGABYTE Control Center (GCC)
- Q-Flash & Q-Flash Plus
- Smart Backup
|
|
Software Tambahan
|
- Norton® Internet Security (OEM)
- LAN Bandwidth Management
|
|
Sistem Operasi
|
- Windows 11 64-bit (direkomendasikan)
- Tidak ada dukungan resmi untuk Windows 10
|
|
Form Factor
|
ATX (30.5 cm x 24.4 cm)
|
