NOCTUA NH-L12S CPU COOLER

Cooler Specification

Socket Compatibility

Intel LGA1851, LGA1700, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 and AMD AM5, AM4

Height (without fan)

70 mm

Width (without fan)

128 mm

Depth (without fan)

146 mm

Weight (without fan)

390 g

Height (with fan)

70 mm

Width (with fan)

128 mm

Depth (with fan)

146 mm

Weight (with fan)

520 g

Material

Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating

NSPR

88

Max. TDP

See NSPR

Fan Compatibility

120x120x15 & 120x120x25

Scope of Delivery

- 1x NF-A12x15 PWM premium fan
- NA-RC7 Low-Noise Adaptor (L.N.A.)
- NT-H1 high-grade thermal compound
- SecuFirm2™ mounting kit
- Noctua metal case-badge

Warranty

6 Years

FAN Specification

Model

1x Noctua NF-A12x15 PWM

Bearing

SSO2

Max. Rotational Speed (+/- 10%)

1850 RPM

Max. Rotational Speed with L.N.A. (+/- 10%)

1400 RPM

Min. Rotational Speed @ 20% PWM (+/-20%)

450 RPM

Max. Airflow

94,2 m³/h

Max. Airflow with L.N.A.

70,8 m³/h

Max. Acoustical Noise

23,9 dB(A)

Max. Acoustical Noise with L.N.A.

16,8 dB(A)

Input Power (max.)

1,56 W

Voltage Range

12 V

MTTF

> 150.000 h
